Flange Mounted Balanced Head Fairlead
Flange Mounted Balanced Head Fairlead
| Product No. | Max Wire Size (inch) | Wire Breaking Strength (1bs) | Sheave Tread Dia (inch) | Measurements (inch) | Weight (1bs) | |||||
| A | B | C | D | E | F | |||||
| BMMMEBFFM-001 | 3/4 | 58,800 | 8 1/4 | 21 7/16 | 16 | 19 1/8 | 8 3/8 | 9 | 4 1/2 | 255 |
| BMMMEBFFM-002 | 1 | 103,400 | 9 3/4 | 25 7/16 | 17 | 23 1/8 | 10 3/8 | 11 | 5 5/8 | 363 |
| BMMMEBFFM-003 | 1 1/4 | 159,800 | 11 1/4 | 27 11/16 | 18 3/4 | 26 5/8 | 10 5/8 | 11 3/4 | 6 5/16 | 560 |
| BMMMEBFFM-004 | 1 1/2 | 228,000 | 14 1/4 | 35 1/8 | 25 | 34 1/4 | 13 3/4 | 16 | 8 1/2 | 1160 |
| BMMMEBFFM-005 | 1 3/4 | 266,000 | 18 1/2 | 42 1/8 | 27 | 43 1/2 | 16 | 18 | 9 1/2 | 1722 |
| BMMMEBFFM-006 | 2 | 344,000 | 20 | 47 | 30 | 42 3/4 | 17 3/4 | 20 | 12 | 2067 |
| BMMMEBFFM-007 | 2 1/4 | 494,000 | 24 7/8 | 53 7/8 | 35 1/2 | 58 3/4 | 22 1/4 | 24 | 13 | 3936 |
| BMMMEBFFM-008 | 2 1/2 | 524,000 | 30 | 59 1/2 | 39 | 68 1/4 | 24 1/4 | 26 | 14 1/2 | 5100 |
| BMMMEBFFM-009 | 3 | 818,000 | 44 | 102 5/8 | 60 | 98 | 41 | 39 1/2 | 26 1/2 | 15400 |
| BMMMEBFFM-010 | 3 | 818,000 | 55 1/2 | 115 5/8 | 60 | 117 1/2 | 41 | 39 1/2 | 26 1/2 | 17700 |
