Controllable Pitch Propeller HS Series



Technology & Parameters:

Product No. Type Hub Dia. a b c d e Vmin
BMMPP-CPP HS001 HSCP-1095 1095 961 470 256 1014 115 260
BMMPP-CPP HS002 HSCP-1190 1190 1043 502 272 1096 115 275
BMMPP-CPP HS003 HSCP-1300 1300 1127 548 295 1201 130 295
BMMPP-CPP HS004 HSCP-1415 1415 1225 589 314 1298 130 320
BMMPP-CPP HS005 HSCP-1540 1540 1346 638 337 1415 160 345
BMMPP-CPP HS006 HSCP-1680 1680 1466 686 362 1544 160 375
BMMPP-CPP HS007 HSCP-1835 1835 1584 745 397 1679 160 400
BMMPP-CPP HS008 HSCP-1915 1915 1650 777 412 1752 160 415
BMMPP-CPP HS009 HSCP-2000 2000 1724 810 430 1825 190/160 435

*HS type contollable pitch propeller is servomotor in Hub,Oil supply unit in shaft.
*Our controllable-pitch propellers are propulsion systems that can be used with almost any type of vessel. The power spectrum ranges from 600 kW to 10,000 kW, with propeller sizes varying between approxima -tely 1.5 to 5.0 metres.

*Advanced calculation methods allow the controllable-pitch propeller systems to be optimally adapted to the vessel’s hull form, thereby maximizing efficiency and minimizing noise generation. The simple structure and the robust design keeps maintenance requirements to a minimum and ensures it a long service life.

*Features include:
Compact, well proven, strong hub designs
Few components, robust design
Small overhang weight
Accurate stepless hydraulic pitch control
Reduced hydraulic power requirement
Easy to install, delivered as pre-assembled complete system
Under water replacement of blades
