Technology & Parameters:

Type	CPL-165 vertical magnetic compass
Project	Data
Card diameter	ф165mm
Graduation	1°(0~360°)
Use temperature	-30℃+60℃
Direction error	≤0.5°
Swing semi-period	≥8.27S
Friction error	≤0.08°
The main semicircular deviation correction of energy	1°~45°
A semicircular deviation correction of energy	1°~6°
Quadrant deviation correction	0.5°~10°
Heeling error correction	-75~+75µΤ
illumination	AC220V,DC24V
Overall dimensions	740*460*1350mm
Carton size	790*540*1290mm
installation dimensions	Pitch420Apertureф14
Net weight	About 33kg
